Corrosion Proof Hook Type Shot Blasting Machine for Forging Parts and Small Castings
Product Details:
| Place of Origin: | China |
| Certification: | ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, HSE, QC 080000, BSCI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Delivery Time: | Peak Season Lead Time: 1-3 months Off Season Lead Time: 1-3 months |
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment |
| Supply Ability: | 500 Sets Per Years |
|
Detail Information |
|||
| Model NO.: | Q379 | Fuel: | Electric |
|---|---|---|---|
| Type: | Rotary Abrator | Cleanliness: | High Cleanliness |
| Automation: | Automatic | Feature: | Rust / Corrosion Proof |
| Condition: | New | Customized: | Customized |
| Transport Package: | Cargo | Specification: | 4470*3315*5365mm |
| Trademark: | Pumingwwei | Origin: | China |
| HS Code: | 8424300000 | Supply Ability: | 500 |
| Customization: | Available | After-sales Service: | One Years |
| Warranty: | One Years | ||
Product Description
Q379 Hook Type Shot Blasting Machine with Forging Parts and Small Castings
Reference FOB Price US $10,000.00-80,000.00
| After-sales Service: | Technical Support for Customer |
|---|---|
| Warranty: | One Year |
| Application: | Metal Surface Derusting |
| Fuel: | Electric |
| Type: | Crawler Abrator |
| Cleanliness: | High Cleanliness |
Basic Info.
Model NO. Q379
Automation Automatic
Feature Derusting and Efficiency
Condition New
Customized Customized
Terms of Payment T/T and So on
Hanger Single and Double Hook
Size 4470*3315*5365mm
Weight 2500kg
Factory Experience 20 Years
Transport Package Foam, Pallet and Plastic Film
Specification international standard or customized
Trademark Pumingwei
Origin China
Production Capacity 500 Sets Per Years
Product Description
Q37series hook shot blasting machine
This series hook type shot blasting machine is suitable for surface cleaning or strengthening treatment of small casting and forgings in industry for casting,building,chemical,motor and machine tool,mainly used for devoted to all types of small quantity surface cleaning and shot-blasting strengthening of castings,forging and steel structure parts and other spare parts to clear little viscous steel grit,grit core and oxide skin,also suitable for surface cleaning and strengthening on heat treatment parts,which is particularly useful for cleaning of tiny and thin wall parts which is less vulnerable to impact.
Product Parameters
| Parameter Type | Q375 | Q376 | Q378 | Q378A | Q378E | Q379 | Q3710 |
| The max single hook weight/kg | 500 | 500 | 800 | 800 | 800 | 1000 | 1000 |
| The max castings size/mm | 1000*1400 | 800*1100 | 800*1500 | 1000*1800 | 1400*1500 | 900*1500 | 1100*2500 |
| Cleaning room size/m | 1.6*1.6*2.15 | 1.6*1.6*2.15 | 1.6*1.6*2.15 | 2.0*2.0*2.75 | 2.0*2.0*2.2 | 2.0*2.0*2.1 | 2.0*2.0*2.5 |
| Production rate | 4-15 | 6-15 | 4-9 | 6-12 | 4-15 | 6-15 | 6-15 |
| Dedusting air volume(m3/h) | 9700 | 2000 | 6000 | 7500 | 5500 | 6600 | 9900 |
| processing capacity of separating system/(t/h) | 20 | 15 | 25 | 25 | 40 | 35 | 45 |
| Impeller head quantity | 2 | 1 | 2 | 2 | 2 | 2 | 3 |
| Single abrasive flow rate(kg/min) | 140 | 220 | 200 | 200 | 240 | 250 | 230 |
| Single power/kw | 7.5 | 11 | 11 | 11 | 15 | 15 | 11 |
| Total power/kw | 27.3 | 20 | 27.4 | 30.5 | 39.6 | 35.6 | 55.5 |
| Overall dimension/mm | 6.37*3.3*5.5 | 6.3*3.2*4.8 | 4.4*3.93*6.42 | 6.0*3.76*7.308 | 5.6*6.1*6.65 | 4.47*3.315*5.365 | 4.809*2.825*7.118 |
After Sales Service
Pumingwei hook type shot blasting machine is professional,unque and irreplaceable
1.Supplier ensure that the name, model, specification and quantity are consistent with technical agreement ,and we
make sure that all machine is new with qualifying product through perfect technology and installation,the quality is
stable and reliable.There are no defects in design, material and technology,which is suitable for proposal of demander.
And meets the standard of national industry.
2.Arrange for engineer or skilled labour to installation and debugging of equipment in overseas.
( except force majeure, inappropriate operation and the quick-wear parts ).
3.In order to ensure a good quality, every machine in the factory will be strict calibration and debugging before they
leave the factory.
4.We will direct the installation and operation of the equipment, and train operators for customer.
